LSZH/FRLS Electric Cable

Voltage: 0.6/1kV
Conductor: Copper or Aluminum Conductor
Insulation: Crosslinked Polyethylene (XLPE)
Armour Type (optional): sta, swa, awa
Outer Sheath: flame retardant low smoke halogen free compound
Standards: CCC/UL/CE/CNAS/IEC Certificate
*FR, FRLS, LSZH, LSOH, LSHF, anti-termite cables are also available.
*Customized products are supported.

O.6/1kV LSZH Cable/ FRLS CABLE

Models

Description

Cores

Cross Section Area

Cu/xlpe/lszh

copper core, xlpe insulated,
flame retardant low smoke halogen free sheath

1 core
2 cores
3 cores
4 cores
5 cores
3+1 cores
3+2 cores
4+1 cores

0.5~1000mm2

Al/xlpe/lszh

Aluminum core, xlpe insulated,
flame retardant low smoke halogen free sheath

Cu/xlpe/lszh/sta/lszh

copper core, xlpe insulated,

flame retardant low smoke halogen free inner sheath,

steel tape armoured,

flame retardant low smoke halogen free outer sheath

4~1000mm2

Al/xlpe/lszh/sta/lszh

aluminum core, xlpe insulated,

flame retardant low smoke halogen free inner sheath,

steel tape armoured,

flame retardant low smoke halogen free outer sheath

Cu/xlpe/lszh/swa/lszh

copper core, xlpe insulated, flame retardant low smoke halogen free inner sheath,

steel wire armoured,

flame retardant low smoke halogen free outer sheath

Al/xlpe/lszh/swa/lszh

aluminum core, xlpe insulated, flame retardant low smoke halogen free inner sheath,

steel wire armoured,

flame retardant low smoke halogen free outer sheath

0.6/1kV LSZH Cable/FRLS Cable Structure

Voltage: 1kV
Conductor: Copper or Aluminum Conductor
(solid class1, stranded class2, class5 )
Insulation: Crosslinked Polyethylene (XLPE)
Shield Layer (optional): Copper tape(CTS)
Copper Wire Braided (CWB)
Armour Type (optional): steel tape armoured (sta)
steel wire armoured (swa)
aluminum wire armoured (awa)
Outer Sheath:

flame retardant low smoke halogen free compound

Standards: CCC/UL/CE/CNAS/IEC Certificate
Additional: *FR, FRLS, LSZH, LSOH, LSHF, anti-termite cables are also available.
*Customized products are supported.

Temperature

XLPE Material:

Max. service temperature: 90 ℃

Min.temperature when installation: 0℃

Max. short-circuit temperature: 250℃ (max. 5s)

Min. service temperature: -40℃ (fixed and protected installations)

Min.Bending Radius

Item

Single Core

Multi core

Unarmored

Armored

Unarmored

Armored

Min. Bending Radius When installation

20D

15D

15D

12D

Minimum bending radius of the cable near the connection box and terminal (bending should be carefully controlled, such as with a formed guide)

15D

12D

12D

10D

* D means overall diameter of cables.

  • High purity thick raw materials

    99.99% Copper/99.6% Aluminum Safety, low resistance, stable voltage, more power saving.

  • Low eccentricity, uniform thickness

    Prevent damage is guaranteed, effectively prevent the current breakdown, to ensure the safety of electricity.

  • Safer use, flame retardant and environment friendly

    All new and high quality sheath, water-resistant and oil-resistant, soft and easy to install.

  • High cost-effectiveness

    Environment friendly, safer use, better quality, low cost and sooner delivery.

  • International standard meets different needs.

    Our products are produced according to Chinese standards (GB/T, ISO9001) and international standards including IEC, BS, DIN, ICEA or according to customers’ requirements. It has also got CCC (China Compulsory Certification) and ISO certificates. Thus, the quality of each product could be guaranteed.

  • Quick response within 24hours.

    Huanghe Cable Group supports you always.

  • Product warranty for one year if the product is correctly installed and used.

  • Professional Team

    Our engineer team support with professional suggestions and solutions. Customized products can be provided based on your specifications.

Features of Low-smoke Halogen-free Flame Retardant Cable

A: Greater Tensile Strength

1.05Kgf/mm2 (ordinary pvc cable)

1.2Kgf/mm2 (FR-LSHF cable)

The tensile strength of low-smoke halogen-free flame retardant (FR-LSHF) cable is much greater than ordinary pvc insulated cable.

A: Good Weather Resistance (-30~105)

A: Excellent Flexibility (hardness 80-90)

A: There won’t be toxic black smoke when the FR-LSHF cable is burning.

A: Higher Volume Resistivity

1.05Kgf/mm2 (ordinary pvc cable)

1016Ω/cm3 (FR-LSHF cable)

A: High Voltage Resistance

A: Good Elasticity
